single pass printer,UIN-PRINT

Single pass UIN-900A digital printer

Single pass UIN-900A digital printer with suction feeding, Newly style digital color inkjet printer, lt can print on the surface of various absorbent materials such as Kinds of paper,absorbent fabric,napkin、non-woven fabric etc, and customize printing with personalized designs without waiting or plate-making.lmport then printing immediately, quick and convenient. Water-based environment ink, CMYK printing . lt is very suitable for rush orders, small orders, color orders, and e-commerce orders.

Send Inquiry

技术参数 Technical Parameters
机器型号 Machine model	UIN-900A
喷头类型 Printhead technology	HP-A3
喷头分辨率 Printhead resolution	1200dpi
喷嘴数量 Number of nozzles	59136(4224*14)
喷头数量 Printhead number	2Pcs
喷头宽度 Printhead width	300mm
喷印宽度printing width	宽度600mm，长度无限制 Printing width 600mm,unlimited length
喷头可升高度printhead rising height	标准喷印高度120mm，可接受高度定制 Standard height 120 mm,accept height customization
墨水类型 Ink type	水性 Water-based ink
可变数据 Variable data	支持喷印可变一维码、二维码、流水号、乱码等，支持数据以及图像可变信息 Support printing one-dimensional code,QR code,serial number,random number,support data and image.
喷印软件 Printing software	Single pass RIP
支持文件 Supporting documents	TIFF、BMP、JPEG、CDR、PSD、JPG 等常见格式
喷印精度 Printing resolution	300dpi/600dpi/1200dpi
喷印速度 Printing speed	0-60m/min
数据接口Data connection	网线口（网口）Network line interface
操作系统 Operating system	Windows7 /Windows8/Windows10/XP
喷印材料 Printing material	各类纸质用品，吸水性布料，纸张，餐巾、无纺布等（具体以实测为准） Kinds of paper,absorbent fabric,napkin、non-woven fabric etc(subject to actual testing)
可放材料宽度Material width	860mm
输送线速度Running speed	0-80m/min
控制方式Control mode	PLC+伺服系统 PLC+servo system
上料方式Feeding model	吸附上料 Suction feeding
电力要求Power requirement	50/60Hz, 110/220VAC 800W
工作环境Operation environment	温度 Temperature15-35℃ 湿度 Humidity20%～60%
机器尺寸 Equipment size	(length)2600mm x(width)1380mm x(height)1550mm
包装尺寸 Packing size	2682mm1410mm1750mm
