Wisdom Corrugated printer
The WisdomPrinter WPC-2008A, a non-plate digital carton printing equipment, is a high-precision fixed direct output carton and cardboard printer. It can be equipped with 4-7 print heads, achieving a maximum precision output of up to 1200*1200 DPI to meet the production needs of customers. The maximum printing width is 1200-2100mm, and a single head can print products with a width of 300mm and an unlimited length. There are no restrictions on document and image formats. It achieves instant order processing with 0-second plate changing, eliminating the need for plate making. With unlimited color options, it can start printing from a single sheet, making it a digital color printing ceiling-level fixed carton printer.
| 技术参数 Technical Parameters | |
|
机器型号 Machine model |
WPC-2008A |
|
喷头类型 Printhead type |
微压电式高精度喷头 Micro PE high precision printhead |
|
喷头数量 Number of printhead |
8PCS |
|
墨水类型 Ink type |
专用纸箱墨水 Cardboard box ink |
|
墨水颜色类型 Ink colors |
C、M、Y、K |
|
喷印高度 Printing Height |
2mm-4mm |
|
印刷精度 Printing resolution |
≥360*600dpi |
|
印刷效率 Printing speed |
80-600 ㎡/hour（不含送料时间） |
|
印刷幅面 Printing format |
自动送料时2600mm*1350mm，手动送料时2600mm*无限长 Automatic feeding 2600mm*1350mm ,Manual feeding 2600mm*limitless |
|
干燥速度 Drying speed |
挂面纸板即印即干，可印涂布纸 Print and dry, and can be printed on coated paper |
|
工作环境 Operation environment |
Temperature20-25℃，Humidity50%-70% |
|
供墨方式 Ink system |
自动连续供墨 Automatic continuous ink supply |
|
送料方式 Material feeding method |
全自动前缘送料系统，吸风分区平台 Fully automatic front edge feeding system, suction partition platform |
|
材料厚度 Media thickness |
3mm-40mm |
|
使用软件 Printing software |
Professional RIP |
|
导轨 Rail |
台湾上银 Hiwin |
|
电机 Motor |
信捷伺服 Xinje sever motor |
|
开关电源 Switch power supply |
台湾明纬 Mean well |
|
皮带 Belt |
日本三阪 Sables |
|
PLC |
信捷 XINJE |
|
前缘 Leading edge |
自研，自产，伺服 Self-developed, Self-produced, Servo |
|
控制操作系统 Operation system |
WIN7/WIN10系统64位操作系统 |
|
电源功率 Power requirement |
About20KW; Power：AC380±10%,50-60HZ |
|
设备尺寸 Equipment size |
（length）5645mm x（width）3750mm x（height）2123mm |
|
设备重量 Equipment |
5000kg |
|
无版喷墨印刷机优势 Advantages Of Plateless Inkjet Printing |
||
|
无 需 制 版 No need for plate making |
无 需 洗 机 No need to machine wash |
环 保 节 能 Environmental protection and energy saving |
|
喷 墨 技 术 Inkjet technology |
一 张 起 印 Print from one sheet |
立 等 可 取 Immediately wait for it |
|
工 艺 简 单 Process is simple |
操 作 方 便 Easy to operate |
省 时 省 力 Save time and effort |
Printing samples
